Milling Machine - Console Type, FP20

 Type  Milling Machine - Console Type
 Model  FP20
 Manufacturer  TOS KURIM
 Year of Manufacture  1973

Specifications - Portal Milling Machine

Working area (mm) 2800 x 1500 x 1100
Motor power (kW) 22
Spindle speed (min-1) 10 - 500
Feed rate (mm/min) 25 - 750 ...stroke
  4000 ... high speed stroke
Table load capacity (kg) 10000
Controller /

Other Characteristics

Accuracy: 0.1 mm, machining without cooling, with crown up to 315 mm in diameter, machining of castings to thickness, operations performed also with rod type milling cutters with 20 mm and larger diameters, face roller milling cutters with 100 mm in diameter and cross-type milling cutters.
