Handheld Optical 3D Scanner

Measuring Area	Up to approximately 600 × 550 mm (scanning area); expandable measuring volume up to 5 m with Satellite Mode
Accuracy	Volumetric accuracy: 0.020 mm + 0.015 mm/m
Point Spacing	Adjustable: 0.05–10 mm
Number of Points	Not fixed; laser line scanner with continuous data acquisition
Software	ZEISS INSPECT / ZEISS Quality Suite
Light Source	Blue laser, Class 2 (eye-safe), multiple blue laser crosses and a single blue laser line
Scanner Weight	< 1 kg
Cable Length	10 m (ultra-light cable)
Working Distance	Automatic working distance guidance using a red laser indicator (Distance Radar)
Calibration	Hyperscale one-shot calibration
Large-Part Measurement	Satellite Mode without coded markers
